iOS SDK reference

Use the iOS SDK settings, events, and actions to customize the behavior of your AI Agent. This page covers the public API of AdaWebHost in the AdaMessaging framework.

Settings

Configure AdaWebHost with input parameters at initialization. The SDK builds the WebView and its URL inside init, so all settings must be set at initialization. To change values later, use the actions.

appScheme

appScheme: String = ""

Use this setting to pass the scheme name of the host app. This allows for more robust handling of universal links.

appUrl

appUrl: String = ""

Overrides the app frame URL that the Messaging runtime mounts.

The value must be an absolute https: URL. The runtime drops invalid values with a logged warning and mounts the default app instead. If the custom app fails to load or complete its handshake, the runtime falls back to the default app.

For local development against a simulator, expose your development server through an https: tunnel, and add the tunnel origin to Allowed websites. The dashboard accepts only https:// entries. On the production and pre-production environments, the WebView’s host page is an Ada asset origin, not a loopback page. The web SDK’s implicit loopback allowance therefore does not apply there.

The exception is the local asset-server environment (.local), used for SDK development. Its WebView host page is https://localhost:4900, a loopback origin, so the implicit loopback allowance applies and a loopback appUrl such as http://localhost:5173 needs no entry.

The value is delivered to the web runtime through an injected configuration object, not through the WebView URL. It applies only when webSdk is .messaging. The legacy runtime ignores it.

cluster

cluster: String = ""

Specifies the cluster your AI Agent runs on. Set this only if your Agent is hosted on a non-default cluster (for example, us2, maple, eu). If the Agent is on the default cluster, leave this unset.

deviceToken

deviceToken: String = ""

The APNs device token for push notifications. On the legacy runtime, the SDK forwards the token at initialization, so it is present from the first message the end user sends. On the Messaging runtime, the SDK registers the token once the runtime is ready. It is not folded into the initialization payload on the Messaging runtime, unlike the Android SDK. The token never appears in a URL. To set or rotate the token after initialization, use setDeviceToken.

domain

domain: String = ""

The Ada domain your AI Agent is served from.

embedVersion

embedVersion: String = ""

Pins the legacy runtime’s host page to a specific embed build. Used for pre-release verification with your Ada team. Leave blank for the stable rollout. Ignored when webSdk is not .legacy.

enableProgrammaticControl

enableProgrammaticControl: Bool = false

Opts this host into the Messaging runtime’s programmatic-control API. When set to true, your app can:

• Call sendMessage.
• Receive the ada:message:sent and ada:message:received events in eventCallbacks.

While the flag is false (the default), sendMessage is rejected with ProgrammaticControlNotEnabled and those events are not delivered.

This setting applies only when webSdk is .messaging. The legacy runtime ignores it.

environment

environment: AdaEnvironment? = nil

The deployment environment that hosts the WebView entry page and SDK assets. See AdaEnvironment. Most production apps set .production.

eventCallbacks

eventCallbacks: [String: (_ event: [String: Any]) -> Void]? = nil

A dictionary of callbacks keyed by event name. See Events for the delivery contract and the list of event keys.

let adaWebHost = AdaWebHost(
    handle: "my-agent",
    eventCallbacks: [
        "ada:message:received": { event in
            // A message arrived from the AI Agent or a human agent.
        },
        "*": { event in
            // Every event, keyed by event["event_name"].
        }
    ],
    environment: .production,
    webSdk: .messaging,
    enableProgrammaticControl: true
)

greeting

greeting: String = ""

Use this setting to customize the greeting messages that new end users see. This is useful for setting view-specific greetings across your app. The greeting should correspond to the ID of the Answer you would like to use, which you can find in the URL of the corresponding Answer in the dashboard.

Example

handle

handle: String

The handle for your AI Agent. This is a required field.

headless

headless: Bool = false

When set to true, the Messaging runtime connects to your AI Agent without rendering its default chat UI. Use this when your app renders its own conversation UI with native components and drives the conversation through sendMessage and eventCallbacks.

Headless hosts are typically paired with enableProgrammaticControl: true. Without it, the methods and events needed to drive a custom UI are rejected at runtime.

headless suppresses only the runtime’s UI. To run the WebView without presenting it, launch with launchHeadlessWebSupport. That action forces this setting to true, and rebuilds the WebView when the host was created without it, so set headless: true at initialization to avoid the extra load. See Headless session lifecycle for the constraints.

This setting applies only when webSdk is .messaging. The legacy runtime ignores it.

identityToken

identityToken: String = ""

A short-lived identity token that authenticates the end user before the session starts. Your backend mints the token with the Ada Platform API, then your app passes it here. See Authenticate end users for the setup flow.

Token handling rules:

• Tokens are single use and expire after 15 minutes. Mint a fresh token for each new AdaWebHost.
• The SDK delivers the token to the web runtime through a one-time injected configuration object at document start. The token never appears in a URL, so it stays out of request logs.
• The SDK holds the token in memory only. It is never persisted to disk.
• The SDK remembers when the runtime has consumed the token. If the host rebuilds or reloads its WebView, the spent token is not delivered again. Create a new host with a newly minted token to re-authenticate.
• Exchange failures surface as the ada:identity_token:error and ada:identity_token:expired events.

This setting applies only when webSdk is .messaging. The legacy runtime ignores it.

language

language: String = ""

Sets the initial display language. To use the same language for AI Agent replies, first turn languages on in your Ada dashboard. Go to Customization > Languages. See Support multiple languages in the same AI Agent for more information.

With the Messaging runtime, this setting applies on every WebView launch and takes precedence over a saved language choice. A language picker or setLanguage change during that launch is still saved when session persistence is enabled. This setting takes precedence again on the next launch. Omit this setting to allow a saved choice to restore.

Later language updates from the Agent or another widget sharing the session can change the display language. With session persistence enabled, the widget saves its current display language.

When activation restores an existing session, it synchronizes the configured language if the Agent supports it. If the reply language changes, other open widgets using the same session apply the update live, even during a conversation.

If the Agent does not support the display language, or the language update fails, the display language can differ from the Agent’s reply language. An unsupported configured value can still replace a supported saved choice when session persistence is enabled.

metafields

metafields: [String: Any] = [:]

Use metafields to pass information about a user to Ada at initialization. This can be useful for tracking information about your customers, as well as personalizing their experience.

To change these values after initialization, use the setMetaFields action.

lazy var adaWebHost = AdaWebHost(handle: "my-agent", metafields: ["tier": "pro"])

navigationBarOpaqueBackground

navigationBarOpaqueBackground: Bool = false

When set to true, the modal presentation uses a full-screen style with an opaque, light-gray navigation bar and status bar. Applies to launchModalWebSupport only.

openWebLinksInSafari

openWebLinksInSafari: Bool = false

External web links open by default in-app, via SFSafariViewController. To open external links in the Safari browser, pass openWebLinksInSafari: true.

sensitiveMetafields

sensitiveMetafields: [String: Any] = [:]

Use this parameter to pass sensitive meta information about an end user. This works like metafields but provides an added layer of security.

The SDK forwards these fields at initialization, so an identified session carries them from the first message. On the legacy runtime they ride the start config. On the Messaging runtime they ride a document-start injection. The values never appear in a URL.

To change these values after initialization, use the setSensitiveMetaFields action.

styles

styles: String = ""

Passes style overrides to the web runtime. The value’s meaning depends on webSdk:

• .legacy: a CSS style override string.
• .messaging: no effect. The runtime ignores the value and logs a warning.

version

version: String = ""

Pins the legacy runtime’s chat bundle to a specific build. Used for pre-release verification with your Ada team. Leave blank for the stable rollout. Ignored when webSdk is not .legacy.

webSdk

webSdk: AdaWebSdk = .legacy

Selects which web runtime the WebView mounts. See AdaWebSdk.

• .legacy (the default) keeps the runtime the previous AdaEmbedFramework SDK loaded, so migrating apps see no behavior change.
• .messaging mounts the Messaging runtime. headless, identityToken, enableProgrammaticControl, and sendMessage require it.

Set an explicit environment when you select .messaging.

webViewLoadingErrorCallback

webViewLoadingErrorCallback: ((Error) -> Void)? = nil

Called when the WebView fails to load. Receives an AdaWebHostError: .webViewTimeout when loading exceeds webViewTimeout, or .webViewFailedToLoad for navigation failures.

webViewTimeout

webViewTimeout: Double = 30.0

The number of seconds the SDK waits for the WebView to load before it stops loading and calls webViewLoadingErrorCallback with .webViewTimeout.

zdChatterAuthCallback

zdChatterAuthCallback: ((@escaping (_ token: String) -> Void) -> Void)? = nil

Use zdChatterAuthCallback to authenticate Zendesk Chat and Zendesk Messaging Handoffs. For Zendesk Messaging, select the Messaging runtime. Request a JWT from your server and pass it to the callback.

lazy var adaWebHost = AdaWebHost(handle: "my-agent", zdChatterAuthCallback: { callback in
    // Request JWT from your API
    // Then...
    callback("your.JWT")
})

For Zendesk Messaging, return your Zendesk Messaging authentication JWT. Sign it with a Zendesk Messaging signing key using HS256. Include the signing key ID in the kid header. Include the scope: "user", external_id, and exp claims. Set exp to an expiry time in Unix seconds. Keep the signing secret on your server.

The external_id must be a non-empty string of at most 255 characters. It must not contain /, ?, #, %, whitespace, or control characters. The JWT can include name and email, but Ada does not store these claims for Messaging authentication.

The SDK requests one token at startup, including when both Zendesk platforms are configured. Zendesk Messaging authentication does not require the Zendesk Chat feature. Existing Zendesk Chat callbacks need no changes.

Ada finds or creates the Sunshine user under that external_id when the Handoff starts.

After successful verification, the server stores the identity and its validity window on the end user record. Each successful startup check renews the window for 24 hours. Browser metadata cannot supply or change these values.

If no valid token or signing secret is available, the Handoff uses an anonymous Sunshine user unless another identity mapping applies. When a user signs out, call adaWebHost.reset() so the next user starts a new conversation and a new Zendesk user. See Authenticate end users for signing key setup.

Session persistence

The web runtime keeps the working copy of session state inside the WebView’s web storage. From version 1.3.0, the SDK also stores a session mirror in the Keychain. If the end user force-quits the app, the SDK restores the session from the session mirror on the next launch. The restored session includes active live agent handoff context. The native side also caches a small allowlist of cosmetic state, with a 10 minute expiry, to smooth the next launch.

Session persistence has these properties:

• The session mirror follows your AI Agent’s persistence setting. The normal persistence mode writes the session mirror. The session and private persistence modes clear the session mirror, so the SDK writes no session mirror in these modes.
• The session mirror is this-device-only. The Keychain entry does not sync to iCloud and does not transfer to another device.
• The session does not survive an app uninstall. This behavior is deliberate. After a reinstall, a first-run check wipes old Keychain entries, and the SDK starts a fresh session.
• An identityToken always takes precedence. If you supply a token at start or at reset, the SDK performs the identity exchange first. The resolved session replaces any previously persisted session.

Session persistence shows no end-user prompts, permission dialogs, or biometric sheets. It requires no new host-app permissions. The SDK never persists identity tokens to disk.

Events

Pass an eventCallbacks dictionary at initialization to receive runtime events.

The delivery contract:

• Each callback receives one [String: Any] dictionary.
• event["event_name"] is the event key as a String.
• event["data"] carries the event payload when the runtime sends one.
• The callback registered under the exact event key fires first, then the callback registered under "*" fires with the same event.
• The "*" callback receives every event the runtime emits, including keys not listed below.

The dictionary holds one closure per key. To register several subscribers for the same key, or to add and remove subscribers after initialization, use addEventCallback and addSdkEventCallback instead. Subscribers registered that way also receive the ada.bridge.error and ada.webview.* events under their own keys, not only under "*".

Common event keys, in alphabetical order:

Headless session lifecycle

A headless host is an offscreen integration, not a background service. The following constraints are firm:

• No background execution. iOS suspends the WebView’s content process when the app is suspended. Events do not arrive while the app is not running. Use push notifications through setDeviceToken for delivery outside the app lifecycle.
• App termination ends the runtime. When the app terminates, the WebView and its in-memory state are gone. On the next launch, the session rehydrates from the runtime’s own web persistence, or from the session mirror.
• Tokens are never persisted natively. identityToken is held in memory and consumed once by the runtime. Mint a fresh token for each new host.
• One WebView per host. Each AdaWebHost owns one WebView. Retain the host for as long as you need the session. Releasing it stops event delivery.
• Keep the container out of user interaction. A hidden or zero-sized container is fine. WebKit can throttle rendering for offscreen views; command dispatch and event delivery still work.

To show the Ada UI later, create a new AdaWebHost without headless and present it with one of the launch actions. The conversation continues because the runtime persists session state in web storage.

Actions

Use the actions below in conjunction with settings to customize the behavior of your AI Agent in an iOS app. On the Messaging runtime, actions called before the runtime is ready are queued and dispatched when sdk.ready fires.

addEventCallback

addEventCallback(_ eventName: String = "*", callback: @escaping (_ event: [String: Any]) -> Void) -> AdaEventSubscription

Registers a callback for one event key, or for every event with the default "*" key. Unlike the eventCallbacks dictionary, which holds one closure per key, any number of callbacks can subscribe to the same event, and you can subscribe after initialization. Returns an AdaEventSubscription token. Pass the token to removeEventCallback to unsubscribe.

let subscription = adaWebHost.addEventCallback("ada:message:received") { event in
    // A message arrived from the AI Agent or a human agent.
}

Subscribers registered this way also receive the ada.bridge.error and ada.webview.* events under their own keys.

addSdkEventCallback

addSdkEventCallback(_ callback: @escaping (_ key: String, _ data: String?) -> Void) -> AdaEventSubscription

Registers a raw sink that receives every event as its key plus its JSON-encoded data. Use it to forward events without knowing the keys in advance. Returns an AdaEventSubscription token for removeSdkEventCallback.

let subscription = adaWebHost.addSdkEventCallback { key, data in
    analytics.track(key, payload: data)
}

clearPersistedState

clearPersistedState()

Removes the natively persisted state. This includes the allowlisted, non-sensitive startup and branding state in UserDefaults. From version 1.3.0, it also includes the persisted session mirror in the Keychain. Call it when an end user signs out. The next WebView session starts without rehydrated state. See Session persistence.

The method returns no result. To confirm the wipe, use clearPersistedStateDurably.

The call does not touch the web runtime’s own storage. To clear the conversation itself, use deleteHistory or reset.

adaWebHost.clearPersistedState()

clearPersistedStateDurably

clearPersistedStateDurably() -> Bool

Removes the same natively persisted state as clearPersistedState, and returns the result. The method returns false when the SDK could not confirm the session-mirror wipe in the Keychain. If the method returns false, call it again.

This method blocks the calling thread. AdaWebHost runs on the main actor, so the blocked thread is the main thread. The block lasts until the wipe completes or a timeout of about 3 seconds elapses. Use clearPersistedStateDurably(completion:) instead, unless your sign-out flow needs the result inline. The method does not touch the web runtime’s own storage.

let cleared = adaWebHost.clearPersistedStateDurably()

clearPersistedStateDurably(completion:)

clearPersistedStateDurably(completion: @escaping @MainActor @Sendable (Bool) -> Void)

Removes the same natively persisted state as clearPersistedState. The SDK calls completion on the main actor with the result. The method does not block. The result is false when the SDK could not confirm the session-mirror wipe in the Keychain. If the result is false, call the method again. Prefer this form for a sign-out on the main actor.

adaWebHost.clearPersistedStateDurably { cleared in
    if !cleared {
        // Retry the sign-out wipe.
    }
}

deleteHistory

deleteHistory()

Deletes the record used to fetch conversation logs for an end user from local storage. When the user opens a new chat window, a new user record will be created.

adaWebHost.deleteHistory()

launchHeadlessWebSupport

launchHeadlessWebSupport(in hostView: UIView? = nil)

Runs the web runtime without presenting any Ada UI. Attaches the WebView to hostView when one is supplied (keep it hidden or zero-sized), or to an internal hidden zero-sized container otherwise.

Requirements and behavior:

• Requires webSdk: .messaging. Calling it on a legacy host stops the program with a precondition failure, matching the Android SDK’s headless factory.
• Forces headless to true. When the host was created with headless: false, the SDK rebuilds the WebView so the runtime loads in headless mode. Set headless: true at initialization to avoid the extra load.

Drive the conversation natively through eventCallbacks and sendMessage. See Headless session lifecycle.

// Offscreen: the SDK creates and retains a hidden container.
adaWebHost.launchHeadlessWebSupport()
// Or attach to your own container. Keep it hidden or zero-sized.
adaWebHost.launchHeadlessWebSupport(in: myHiddenContainerView)

launchInjectingWebSupport

launchInjectingWebSupport(into view: UIView)

Launches Ada chat into a specified subview.

adaWebHost.launchInjectingWebSupport(into: injectingView)

launchModalWebSupport

launchModalWebSupport(from viewController: UIViewController)

Launches Ada chat in a modal view over top of your current view.

adaWebHost.launchModalWebSupport(from: self)

launchNavWebSupport

launchNavWebSupport(from navController: UINavigationController)

Pushes a view containing Ada chat to the top of your navigation stack.

adaWebHost.launchNavWebSupport(from: navigationController)

removeEventCallback

removeEventCallback(_ subscription: AdaEventSubscription)

Removes exactly the callback that addEventCallback returned the subscription for. Unknown subscriptions are a no-op.

removeEventCallbacks

removeEventCallbacks(_ eventName: String = "*")

Removes every callback registered through addEventCallback for one event key, or for "*" by default.

removeSdkEventCallback

removeSdkEventCallback(_ subscription: AdaEventSubscription)

Removes the raw sink that addSdkEventCallback returned the subscription for.

reset

reset(
    language: String? = nil,
    greeting: String? = nil,
    metaFields: MetaFields.Builder,
    sensitiveMetaFields: MetaFields.Builder,
    resetChatHistory: Bool? = true
)

Creates a new end user and refreshes the chat, optionally with a new language, greeting, and metadata. Overloads exist with only metaFields, only sensitiveMetaFields, or neither.

resetChatHistory is tri-state: true and false are sent to the runtime explicitly, while nil omits the value so the runtime’s own default applies. The parameter defaults to true.

adaWebHost.reset(
    language: "en",
    metaFields: publicFields,
    sensitiveMetaFields: sensitiveFields,
    resetChatHistory: true
)

sendMessage

sendMessage(_ body: String)

Sends a message from the end user into the conversation. Use this to drive the conversation from your own native UI.

adaWebHost.sendMessage("Where is my order?")

Requirements and behavior:

• Requires webSdk: .messaging. On the legacy runtime the call is dropped with a debug log.
• Requires enableProgrammaticControl: true. Without it, the runtime rejects the command with ProgrammaticControlNotEnabled.
• Calls made before the runtime is ready are queued and dispatched when sdk.ready fires.

setDeviceToken

setDeviceToken(deviceToken: String)

Sets or rotates the APNs device token used for push notifications. Safe to call before the runtime is ready; the SDK delivers the latest token once the runtime signals sdk.ready.

adaWebHost.setDeviceToken(deviceToken: "apns-device-token")

setLanguage

setLanguage(language: String)

Changes the language in chat programmatically. Use this action, rather than the language setting, to change the chat language without clearing the chat history. Language codes must use a lowercase, two-letter code, in ISO 639-1 language format.

adaWebHost.setLanguage(language: "fr")

Before using setLanguage, you must turn languages on in your Ada dashboard. Go to Customization > Languages. See Support multiple languages in the same AI Agent for more information.

setMetaFields

setMetaFields(builder: MetaFields.Builder)

Sets metadata for an end user after initialization. This is useful if you need to update user data after Ada has already launched. See also metafields.

let publicFields = MetaFields.Builder()
    .setField(key: "firstName", value: "Jane")
    .setField(key: "tier", value: "pro")
adaWebHost.setMetaFields(builder: publicFields)

setSensitiveMetaFields

setSensitiveMetaFields(builder: MetaFields.Builder)

Sets sensitive metadata for an end user after initialization. This works like setMetaFields and is useful for passing more private and sensitive information. See also sensitiveMetafields.

let sensitiveFields = MetaFields.Builder()
    .setField(key: "authToken", value: "secure-session-token")
adaWebHost.setSensitiveMetaFields(builder: sensitiveFields)

Curated bridge requests

AdaWebHost exposes a fixed set of methods that ask the running chat for state or drive it. Each method takes a completion closure. The closure receives one AdaBridgeRequestResult. That result is .success(Any?), .unsupported, or .failure(String).

A method reports .unsupported when the running runtime build does not implement it. A method reports .failure in any of three cases:

• The runtime returns an error, such as a bad argument.
• No answer arrives before the request times out.
• The runtime sends a malformed response that carries none of a result, an error, or an unsupported outcome.

A method never silently does nothing.

Reads return public models only. No read returns sensitive meta fields, the internal stores, or persisted session data. Writes and triggers succeed with a nil value.

Calls made before the runtime is ready are queued and dispatched when the runtime becomes ready. Reads take a required completion closure. Writes and triggers take an optional completion closure. Only the message reads getConversation and getMessages require enableProgrammaticControl. That setting defaults to false. The other reads, writes, and triggers do not. The default differs per platform. React Native defaults it to true. There the same two reads resolve without the flag.

adaWebHost.getConversation { result in
    if case let .success(conversation) = result {
        // Use the public conversation model.
    }
}
adaWebHost.setTheme(.dark)

Types

AdaEnvironment

AdaEnvironment selects the deployment environment that hosts the WebView entry page and SDK assets.

AdaEventSubscription

An opaque token returned by addEventCallback and addSdkEventCallback. Keep it to remove the subscription later with removeEventCallback or removeSdkEventCallback.

AdaWebHostError

AdaWebHost.AdaWebHostError is the error type passed to webViewLoadingErrorCallback.

AdaWebSdk

AdaWebSdk selects which web runtime the WebView mounts. See webSdk.

MetaFields.Builder

MetaFields.Builder builds the metadata payload for setMetaFields, setSensitiveMetaFields, and reset. setField(key:value:) accepts String, Bool, Int, Float, and Double values and returns the builder for chaining.

let fields = MetaFields.Builder()
    .setField(key: "plan", value: "pro")
    .setField(key: "signedIn", value: true)
    .setField(key: "seats", value: 5)
